Elventive Tech: An Exceptional Provider of PCB Procurement and Designing

Well-engineered PCBs are important components responsible for maintaining system reliability and functionality in any industrial environment. Built to endure extreme heat and vibration, minimise failure risks, and ensure equipment runs without interruption.

Introducing

High voltage IGBT gate drivers

Elventive's high voltage digital gate drivers cater to low and high power, high voltage, and high availability applications for IGBTs and SiC MOSFETS.

Elventive Tech has started to make its mark in the world of PCB design and assembly, bringing a fresh approach for creating printed circuit boards that perform at the highest level of precision and reliability. Since 2021, we have helped several entities from small startups testing their new concepts to established corporations looking for a full-scale production partner. We offer solutions for every phase of the PCB lifecycle, whether you're looking for ongoing support or targeted assistance when your project needs it most.

Elventive

Reliable and Rapid Assembled PCBs

How may we help you?

SMT Assembly

"Efficiency Meets Innovation" – Our Surface Mount Technology (SMT) assembly ensures components fit with pinpoint precision, creating reliable and innovative products.

Through-Hole Assembly

"Strong Foundations for Strong Innovations" – We make sure your components are firmly in place, providing durable, dependable results for every application.

Prototype Assembly

"Bring Your Ideas to Life" – Refine your concepts with our prototype assembly service, setting the stage for seamless mass production.

Turnkey PCB Assembly

"From Concept to Completion" – We take care of everything from sourcing parts to testing, so your product is ready for the spotlight.

Strategy For Bringing the Best to Each PCB Project

The foundation of any successful electronic product lies in its PCB. The PCB design and assembly process Elventive uses is strategized for efficiency and high performance. Right from the initial design phase, our team does the needful to understand the project requirements to ensure the PCB layout project is accurately designed for the specified applications. This includes an early focus on design for manufacturability (DFM), the designing process covers everything from schematic capture and component selection to layout design, ensuring all electrical and mechanical specifications are met.

Making an amazing idea work in real-life scenarios often starts with a prototype. Elventive provides prototype PCB assembly to help clients test their designs before committing to full production. This is crucial for developers looking to adjust their designs through iterative testing. Our rapid PCB prototyping services use advanced techniques like laser direct structuring (LDS) and 3D printing to create prototypes that closely mimic the final product. This allows for immediate testing of concepts and enables engineers to catch and fix design flaws at the earliest, reducing both costs and time to market.

For companies that need a complete solution, full turnkey PCB assembly handles the entire process, from sourcing components to the final assembly. Elventive’s end-to-end service offers easy integration with every aspect of PCB production, including box build solutions, where we help assemble the entire electronic product and not just stop after completing the PCB.

Our team oversees the entire supply chain, collaborating with reliable suppliers to source quality components. We manage the PCB fab and assembly process, including testing and final product assembly, ensuring everything is ready for deployment. This method helps reduce lead times and keeps consistency across product batches

The experts at Elventive have doubled down on refining their specialty in creating IGBT gate driver circuits as they are majorly placed in the power electronics that are used in the automotive and energy generation industry. These circuits demand a high level of precision and performance, as they control the switching of power transistors in high-voltage environments. Our background in industrial PCB solutions means we know how to make boards that can handle tough conditions. We focus on durability while ensuring they always perform in their peak state.

The tech field thrives on innovative ideas, constantly shedding its old skin to evolve into something better. Our PCB Innovation Services include the latest PCB manufacturing technologies to offer custom solutions that will bring the project closer to the client’s expectations. Through constant iteration and refinement, we work together to ensure that each project meets the required standards and performs effectively in the intended environment.

Design Jig Fixture and Engineering Support

Precision is essential in manufacturing, and Elventive offers design jig fixture services to enhance accuracy and repeatability in PCB assembly. Custom jigs and fixtures are created to ensure that each PCB is assembled correctly, which is particularly important for high-volume production, where small assembly errors can lead to significant problems later. The engineering team provides support throughout the PCB development process, focusing on optimizing PCB design for manufacturability (DFM) and ensuring compliance with functional and regulatory standards.

New Product Launch Support

Bringing a new product to market involves several steps, and that process can be exhaustive. Elventive provides support throughout, assisting from the initial design phase to production. For both consumer gadgets and industrial tools, the focus remains on providing a smooth transition from prototype to full-scale production while bypassing potential challenges. This includes help with testing and validation, ensuring that the product performs as expected before it reaches the market. We delightfully offer prototype circuit board assembly services that are scalable, allowing companies to ramp up production as the product demand grows further ahead with time.

Onboarding Process of Elventive:

1.
Get an Instant Quote:

Start by selecting the service that fits your needs and get pricing options for the same.

2.
Choose Your Service:
3.
Fill Board Details:

Provide specifications such as thickness, layers, and finish.

4.
Place Order Online:

Upload design files (Gerber, BOM, etc.) and confirm payment.

5.
Check Order Status:

Track progress and resolve issues in the customer portal.

Our services

New Product Launch Support

Jigs and Fixtures design

Box Build

Complete Turnkey solutions

Process Innovation and Customisation

New Technology Development

Why Choose Elventive?

When you choose Elventive for PCB fab and assembly needs, you are getting a customized solution through the medium of expertly-built PCBs. Our industry-wide reputation as a reliable partner is a result of our dedication to quality, innovation, and customer satisfaction. It means you’ll get the support you need to launch electronic products that can tackle the challenges of the toughest industrial environments.

From prototype circuit board assembly to PCB turnkey solutions for every project, Elventive finds a way to contribute effectively and meaningfully. For more details, check out their website.

Frequently Asked Questions

1. What is prototype PCB assembly?

Prototype PCB assembly involves creating a small batch of printed circuit boards to test the design before full-scale production. This step is crucial in identifying any flaws in the design or manufacturing process. During prototype circuit board assembly, components are soldered onto the board to ensure functionality and performance meet expectations. It allows engineers to make adjustments before moving to mass production, reducing risks and costs associated with errors in the final design.

2. What services does PCB fabrication (PCB fab) provide?

PCB fabrication (PCB fab) is the process of manufacturing the physical printed circuit board. It includes tasks like creating the board layers, etching the copper traces, drilling holes, and applying surface finishes. After the PCB fab and assembly steps, the board is ready for components to be mounted during assembly. PCB fab ensures the board is manufactured to the precise design specifications, maintaining the right thickness, material quality, and durability for the application.

3. What is the difference between PCB fabrication and assembly?

PCB fabrication focuses on building the physical circuit board, which includes etching, drilling, and finishing processes. PCB assembly is the next step where electronic components are mounted onto the fabricated board, through processes like soldering and testing. In simple terms, PCB fab and assembly work together – first, the board is created, and then it’s populated with the necessary components during assembly. Both are vital steps in creating a functional circuit board.

4. What is full turnkey PCB assembly?

Full turnkey PCB assembly is a full-service product where the provider handles everything from sourcing components, fabricating the PCB, assembling the board, and conducting testing. This service offers end-to-end solutions, saving time and effort for companies. With full turnkey PCB assembly, you only need to provide the design files, and the rest is managed by the service provider, ensuring a smooth process from prototype to final product delivery.

5. How do I choose a PCB assembly service provider?

To choose a PCB assembly service provider, consider factors like experience, manufacturing capabilities, and customer reviews. A reliable provider should offer services like full turnkey PCB assembly and other associated services to meet various project needs. Look for companies with a proven track record, quick turnaround times, and the ability to handle both small prototype batches and large-scale production. Ensure they have strong quality control practices to deliver accurate and reliable assemblies.

6. What factors should I consider when prototyping circuit board assembly?

When working on prototype circuit board assembly, key factors include design accuracy, component selection, and testing capabilities. Ensure that the PCB design and assembly service you choose has experience with rapid prototyping and can deliver high-quality boards for testing. The turnaround time, cost, and ability to make quick changes based on testing results are also important. Testing during the prototype PCB assembly phase is crucial to identify and fix potential design flaws before mass production.
